High Precision Wire Products Sale
We can provide customers in automotive, consumer electronics, new energy, metrology, electric power and medical industries, etc. with our precision profiled wire, medical implants, scroll spring flat strip, wiper flat strip, seat and skylight slide rail, precision filter wire, flat square copper wire, flat bead wire, consumer electronic profiles, flat square wire products, etc.
| Material | High quality carbon steel Stainless Steel Special Non-ferrous mtal |
| Dimension | Thickness: 0.2-3.5 mm Width : 1.0-13 mm |
| Tolerance | Thickness: +/-0.003 mm Width : +/-0.008 mm |
| R Angle Type | Natural Angle, R Angle, Special Angle, Rolling Forming Angle |
| Surface treatment | Polishing, brightening surface, phosphating treatment, fogging surface |
| Packaging | Coil (Weight of each coil: 40 - 1,000 kg) |
| Application | Automobile, metrology, medical treatment, new energy and consumer electronics, etc. |
| Specification | |
| Material | High quality carbon steel Stainless Steel Special Non-ferrous mtal |
| Shape | Trapezoidal, I-shaped and various complex profiled sections to support customer customization |
| Dimension | Thickness: 0.2 - 8.0 mm Width : 1.0 - 10.0 mm |
| Tolerance | Thickness: +/-0.003 mm Width : +/-0.008 mm |
| R Angle Type | Natural Angle, R Angle, Special Angle, Rolling Forming Angle |
| Surface treatment | Polishing, brightening surface, phosphating treatment, fogging surface |
| Packaging | Coil (Weight of each coil: 40 - 1,000 kg) Straight-line truncated binding (40-1000 kg per bundle) |
| Application | Automobile, metrology, medical treatment, new energy and consumer electronics, etc. |
Bead wire
- Bead wire is copper plated on a single wire, which can be made into a single or multiple winding bead;
- National standard of bead wire GB/T14450-2016;
- Bead wire material is 72-82 series high carbon hot-rolled wire rod;
- The type and specification of bead steel wire used in car and truck tyres are different. We can all make bead steel wire;
- Ring wires for bicycles, motorcycle tyres, engineering tyres and aircraft wheels can be made.
| Specification | |
| Material | Copper; Bronze; Brass; Copper alloy |
| Dimension | Thickness: 0.03 - 4.5 mm Width : 0.5 - 13 mm Thickness width ratio: No more than 1/50 R Angle : 0.2 - 1.0 mm |
| Packaging | Coil (Weight of each coil: 40 - 1,000 kg) |
| Application | New Energy Motor, 48V Drive Unit, Flexible Flat Cable, Connector, Electromagnetic Wire |
| Industry | Automobile, Medical, New Energy and Consumer Electronics |
